Knipex 97 52 67 DT 4-Mandrel Crimping Pliers f. DT contacts
€448.95
Delivery time 5 working days
Product information "Knipex 97 52 67 DT 4-Mandrel Crimping Pliers f. DT contacts"
Knipex 97 52 67 DT 4-Mandrel Crimping Pliers for DT contacts
Crimps all turned male and female contacts of the DT, DTM and DTP series.
Features:
- Comprehensive capacity: from 0.35 mm² to 3.0 mm² (AWG 22-12).
- Complete: with precision-ground Go/NoGo gauges to check calibration.
- Synchronous feed of the four mandrels achieves optimum crimping results with eight indentations (4/8-Indent).
- Universal positioning aid for flexible adjustment to all contact lengths.
- Repetitive, high crimping quality due to ratchet mechanism (unlockable).
- Position settings for the crimp depth can be clearly read on the pliers.
- Ergonomic design for low-fatigue work: optimised opening width, comfortable multicomponent grips, low manual force required due to lever transmission.
- Go/NoGo gauges allow quick quality control at any time: Go gauge must fit, NoGo gauge must not fit.
Technical Features:
- Dimensions: 230 x 80 x 70 mm
- Weight (kg): 0,815
- Item no: 97 52 67 DT
- EAN: 4003773088820
Product Safety and Downloads
Documents and datasheets
Product safety information
Manufacturer
Knipex-Werk C. Gustav Putsch KG
Oberkamper Straße 13
42349 Wuppertal
Germany
