KS-Tools 914.1220 1/2" SlimPOWER Telescopic reversible ratchet, 72 teeth
Product number:
1931392
Manufacturer no.:
914.1220
EAN:
4042146757512
Weight in kg:
0.63
Product information "KS-Tools 914.1220 1/2" SlimPOWER Telescopic reversible ratchet, 72 teeth"
KS-Tools 914.1220 1/2" SlimPOWER Telescopic reversible ratchet, 72 teeth
Description
- According to DIN 3122 / ISO 3315
- Square drive adaptor to DIN 3120 / ISO 1174 with ball lock
- Reversible
- Very robust as a result of double pin technology
- 180° revolving head
- Fine gearing 72 teeth ratchet mechanism
- Adjustable in 7 steps
- With ejection mechanism on the ratchet head
- Ergonomic 2-component handle with a soft zone
- Matt finish
- Chrome vanadium
Properties
| Handle: | 2 component handle |
| Diameter D: | 33.0 |
| Total length L in mm: | 294,0-432,0 |
| Weight in g: | 620.0 |
| Max. torque Nm: | 610 |
| Attribute function 3: | flexible head |
| Attribute function 2: | reversible |
| Function attribute 1: | revolving |
| Height of head (A): | 16.0 |
| Drive in inch: | 1/2" |
| Tooth: | 72 |
| Packaging contents: | 1 |
| Joint: | yes |
| Ratchet function: | yes |
| Backswing angle: | 5° |
| Norm: | DIN 3120, ISO 1174, DIN 3122, ISO 3315 |
| Material1: | finest chrome vanadium steel, matt finished |
| Repair set: | 914.1220-1 |
