Gedore 1.06/1-E Quick-release puller, 2-arm patter n 90x100 mm
€91.95*
Content:
1 pcs
/ 5
Delivery time 5 working days
Variante
Product number:
107263
Manufacturer no.:
1213830
EAN:
4036976106251
Weight in kg:
1.1
Product information "Gedore 1.06/1-E Quick-release puller, 2-arm patter n 90x100 mm"
Gedore 1.06/1-E Quick-release puller, 2-arm, 90x100 mm
Gedore 1.06/1-E Quick-release puller, 2-arm, 90x100 mm
Features:
- Proven model for safe and fast removal of discs
- wheels
- ball bearings etc.
- Strong drop forged pattern
- Scale for uniform adjustment of the puller legs. Allows centred pulling
- with optimised application of force
- even when extremely high pulling forces are required
- Can be used as external and internal puller by repositioning the legs
- Exchangeable hooks for several clamping depths available as accessories
- Quick release legs for fast
- easy set-up and adjustment
- Upgradeable with hydraulic spindle (see table)
Technical features:
- Number of arms: 2
- Tractive force (max.) [t]: 3
- Hydraulic spindle optional: -
- Net weight [kg]: 1,1 kg
- Usable clamping reach [mm]: 100 mm
- Usable depth of hooked foot d2 [mm]: 12 mm
Gedore Code-Number: 1213830
EAN: 4036976106251
