Gedore 1.06/1A1-B Universal puller, 2-arm pattern, rigid legs with leg brake 140x100 mm
€90.95*
Content:
1 pcs
/ 5
Delivery time 5 working days
Variante
Product number:
993521
Manufacturer no.:
1956345
EAN:
4036976120882
Weight in kg:
1.34
Product information "Gedore 1.06/1A1-B Universal puller, 2-arm pattern, rigid legs with leg brake 140x100 mm"
Gedore 1.06/1A1-B Universal puller, with hook brake
Gedore 1.06/1A1-B Universal puller, with hook brake
Features:
- Strong drop forged pattern
- Pulling legs forged from one piece
- With leg brake - prevents unintentional leg slipping. The leg can be slid along the cross-beam at the push of a button
- Scale for uniform adjustment of the puller legs. Allows centred pulling
- with optimised application of force
- even when extremely high pulling forces are required
- Can be used as external and internal puller by repositioning the legs
- Interchangeable legs available for several clamping depths
Technical features:
- Number of arms: 2
- Number of hooks: 2
- Tractive force (max.) [t]: 3,0
- Hydraulic spindle optional: -
- Net weight [kg]: 1,3 kg
- Usable clamping reach [mm]: 100 mm
Gedore Code-Number: 1956345
EAN: 4036976120882
