Gedore 1.06/2 Universal puller, 2-arm pattern 160x 150 mm
€131.95*
Content:
1 pcs
/ 62
Please request delivery time
Variante
Product number:
107177
Manufacturer no.:
8000580
EAN:
4036976104189
Weight in kg:
3.04
Product information "Gedore 1.06/2 Universal puller, 2-arm pattern 160x 150 mm"
Gedore 1.06/2 Universal puller, 2-arm, 160x150 mm
Gedore 1.06/2 Universal puller, 2-arm, 160x150 mm
Features:
- Proven model for safe and fast removal of discs
- wheels
- ball bearings etc.
- Strong drop forged pattern
- Scale for uniform adjustment of the puller legs. Allows centred pulling
- with optimised application of force
- even when extremely high pulling forces are required
- Can be used as external and internal puller by repositioning the legs
- Interchangeable legs available for several clamping depths
- Upgradeable with hydraulic spindle (see table)
Technical features:
- Typee of use: Internal and external pulling
- Number of arms: 2
- Tractive force (max.) [t]: 5,0
- Hydraulic spindle optional: 1.06/HSP1
- Usable clamping reach [mm]: 150 mm
- Clamping width (max.) external pulling [mm]: 160 mm
Gedore Code-Number: 8000580
EAN: 4036976104189
