Gedore 1.06/HSP2 Hydraulic pressure spindle 12 t

€413.95*

Content: 1 pcs

Delivery time 5 working days

Stk

Product number: 107239

Manufacturer no.: 8116290

EAN: 4036976104042

Weight in kg: 2

Product information "Gedore 1.06/HSP2 Hydraulic pressure spindle 12 t "

Gedore 1.06/HSP2 Grease hydraulic pressure spindle 3/4, 12 t"

For controlled and safe pulling work
Set up for a pressure of 10 t
12 t or 15 t
The thrust piece can be replaced by a tip and extended if necessary
The small pressure spindle is secured with an unscrewing lock to stop any accidental withdrawal
Preparation for use: 1. before use
check that the pressure spindle is screwed out of the cap far enough so that the thrust piece is in the initial position in the hydraulic cylinder
2. unscrew the cap from the spindle body To do this
first loosen the grub screw
3. screw the spindle body from below into the crossbar of the extractor until the spindle body protrudes approx. 60 mm from the crossbar
4. screw the cap onto the spindle body as far as it will go and then fix it by screwing in the setscrew
Application and mode of operation: e.g. HSP3
5. place puller and pre-tension spindle body with wrench SW 41
6. screw pressure spindle SW 17 into cap. The hydraulics are used. The stroke of the pressure piece in the hydraulic cylinder is max. 12 mm. The hydraulically released workpiece can be completely removed by turning the spindle body with the cap SW 41.
7. after use
the pressure spindle SW 17 is turned back to its initial position and the pressure pad is pressed into the hydraulic cylinder

Gedore Code-Number: 8116290
EAN: 4036976104042
