Gedore 1.11/3 Puller, 3-arm pattern 220x170 mm
€187.95*
Content:
1 pcs
/ 5
Delivery time 5 working days
Variante
Product number:
129241
Manufacturer no.:
1731904
EAN:
4036976112795
Weight in kg:
3.2
Product information "Gedore 1.11/3 Puller, 3-arm pattern 220x170 mm "
Gedore 1.11/3 Puller 3-arm 220x170 mm
Gedore 1.11/3 Puller 3-arm 220x170 mm
Features:
- Tried and tested
- strong design for removing discs
- wheels
- ball bearings etc.
- The wide or narrow hook ends
- which can be used on both sides
- press themselves automatically when loaded
- The wide leg ends of the puller 1.11/2
- /3
- /4 and /5 possess 8 mm slots
- so that pulleys or gears may also be pulled off using 8 mm bolts
Technical features:
- Number of arms: 3
- Tractive force (max.) [t]: 7.5
- Hydraulic spindle optional: -
- Usable depth of hooked foot d2 [mm]: 13 mm
- Usable clamping reach [mm]: 170 mm
- Width across flats [mm]: 19 mm
Gedore Code-Number: 1731904
EAN: 4036976112795
