Gedore 4 R 18x19 Flat ring ratchet spanner 18x19 m m
€38.95
Content:
1 pcs
/ 5
Delivery time 5 working days
Variante
Product number:
1851649
Manufacturer no.:
2306832
EAN:
4010886890387
Weight in kg:
0.23
Product information "Gedore 4 R 18x19 Flat ring ratchet spanner 18x19 m m"
Gedore 4 R 18X19 double ring ratchet spanner 18x19 mm
Gedore 4 R 18X19 double ring ratchet spanner 18x19 mm
Features:
- Flat pattern
- Thin walled rings
- UD profile
- Return angle 7° to 14x15 mm
- 6° 16x17 mm to 18x19 mm
- For ratchet loosening and fast tightening
- Vanadium steel 31CrV3
- Non-glare look due to matt chrome-plating
- locking insert and pawl manganese-phosphated
- Hot forged
- Proven GEDORE technology newly combined: Waisted shaft of the No. 7 and the further developed mechanism of the U-20 ratchets
- In combination with adaptor 7 RA or 7 RB (please order separately) the spanner 7 R can be used as a (bit) ratchet
Technical features:
- Width across flats 1 [mm]: 18
- Width across flats 2 [mm]: 19
- Net weight [kg]: 0,23 kg
- Head height 1 [mm]: 11 mm
- Head height 2 [mm]: 11,7 mm
- Width across flats [mm]: 18 x 19
Gedore Code-Number: 2306832
EAN: 4010886890387
| Design/type: | flat, standard length, straight |
|---|---|
| Size: | 18 x 19 mm |
| Spanner type: | Double ring ratchet spanner |
| Unit of measurement: | metric (mm) |
