Gedore IKS 20 1 Screwdriver bit socket 1/4" PH 1
€7.95
Content:
1 pcs
/ 5
Delivery time 5 working days
Variante
Product number:
100986
Manufacturer no.:
6174580
EAN:
4010886617458
Weight in kg:
0.01
Product information "Gedore IKS 20 1 Screwdriver bit socket 1/4" PH 1 "
Gedore IKS 20 1 Screwdriver bit socket 1/4 cross recess PH 1"
Gedore IKS 20 1 Screwdriver bit socket 1/4 cross recess PH 1"
Features:
- Square drive as per DIN 3120 - C 6.3
- ISO 1174
- with ball retention groove
- Hand operated
- knurled for good grip
- Chrome-plated
- Tip
- manganese-phosphated
- Tip as per DIN ISO 8764-1 PH
- Chrome-vanadium steel
Technical features:
- Tip size cross recess (PH): 1
- Net weight [kg]: 0,011 kg
- Drive connector square [inch]: 1/4
- Insert Ø Actuator: 12 mm
- Tip length: 16,0 mm
- Total length [mm]: 28 mm
Gedore Code-Number: 6174580
EAN: 4010886617458
| Design/type: | standard length |
|---|---|
| Drive: | 1/4" (6,3 mm) |
| Screw profiles: | Cross recess |
| Size: | PH-1, PH-2, PH-3, PH-4 |
| Tool type (socket spanner): | Sockets |
