Kukko 204-2 2-Arm Puller 100 X 100 MmSi de Clamping Type
Product number:
1933121
Manufacturer no.:
204-2
EAN:
4021176028328
Weight in kg:
2.04
Product information "Kukko 204-2 2-Arm Puller 100 X 100 MmSi de Clamping Type"
Kukko 204-2 Universal 2-jaw puller with side clamp
Description
- With integrated clamp.
- Mechanical pressure screw.
- Milled thread treated with special coating.
Use
- For removing particularly tight ball bearings, bearing rings and workpieces.
Advantage
- Clamps increase the pressure of the hooks significantly.
- Spindle head band prevents the wrench from slipping off.
- Safe, fast and efficient disassembly.
- Almost all components available as replacement parts, time-saving order process thanks to numbering system.
- Note: Pressure pads from series 600-17 are a good addition if the shaft is hollow and the spindle cannot be supported.
KUKKO quality standards
- Quality made in Germany.
- Strong design, high performance and long service life.
- Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI).
- Safety label to ensure protection of intellectual property.
- A tube of KUKKO special grease included for pressure spindle.
Series 204
| Item no. | EAN 4021176 |
Clamping reach outside mm |
Clamping reach outside inch |
Clamping depth mm |
Clamping depth inch |
Hex drive size mm |
Max. tonne t |
Max. torque Nm |
Weight kg |
| 204-1 | 028243 | 80 | 3 3/16 | 90 | 4 | 19 | 5 | 100 | 1.385 |
| 204-2 | 028328 | 100 | 3 7/8 | 100 | 3 7/8 | 22 | 6 | 120 | 2.04 |
| 204-3 | 028403 | 150 | 5 7/8 | 140 | 5 1/2 | 24 | 7,5 | 175 | 3.16 |
