Kukko 208-02 2-Arm Puller 230 X 190 MmW ith Adjustable Reach Economy Type
Product number:
1933195
Manufacturer no.:
208-02
EAN:
4021176432651
Weight in kg:
2.49
Product information "Kukko 208-02 2-Arm Puller 230 X 190 MmW ith Adjustable Reach Economy Type "
Kukko 208-02 Universal 2-jaw puller with adjustable reach and swiveling jaws
Description
- Curved, swiveling standard puller hooks with height adjustment.
- Two-arm design for space-saving operation.
- Mechanical pressure screw.
- Milled thread treated with special coating.
- If there is adequate free space around the part to be removed, we recommend a 3-jaw puller series 209 for optimal force distribution.
Use
- For removing bearings, gears, discs, etc.
Advantage
- The larger the pulling force, the stronger the puller hook's grip on the workpiece to be removed.
- Universal application thanks to adjustable depths.
- Spindle head band prevents the wrench from slipping off.
- Almost all components available as replacement parts, time-saving order process thanks to numbering system.
KUKKO quality standards
- Quality made in Germany.
- Strong design, high performance and long service life.
- Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI).
- Safety label to ensure protection of intellectual property.
- A tube of KUKKO special grease included for pressure spindle.
Series 208
| Item no. | EAN 4021176 |
Clamping reach outside mm |
Clamping reach outside inch |
Clamping depth mm |
Clamping depth inch |
Number of clamping depth adjustment |
Hex drive size mm |
Max. tonne t |
Max. torque Nm |
Weight kg |
| 208-01 | 432408 | 20 - 170 | 3/4 - 6 3/4 | 95 - 125 | 3 3/4 - 4 7/8 | 2 | 17 | 2 | 20 | 1 |
| 208-02 | 432651 | 20 - 230 | 3/4 - 9 1/16 | 150 - 190 | 5 7/8 - 7 1/2 | 2 | 22 | 2,5 | 50 | 2.49 |
