Kukko 21-0-E Internal Extractor Ø 4,8-6,5Mm With S egmental Gripping Edges

kukko-21-0-e_anwendung_zoom81FdXVKihYgZk

kukko-21-5-e-22-0-1_fotostrecke1_zoom21AMuxtI5smfk

€77.95*

Content: 1 pcs

Prices incl. VAT plus shipping costs

Delivery time 7 working days

Stk

Product number: 1933202

Manufacturer no.: 21-0-E

EAN: 4021176909153

Weight in kg: 0.05

Product information "Kukko 21-0-E Internal Extractor Ø 4,8-6,5Mm With S egmental Gripping Edges"

Kukko 21-0-E Internal extractor with segmented grasp edge

For extracting bearings, bearing outer rings and bushings that lay flat on one another.

Description

The segmented design with extra fine grasp edges ensures safe extraction.
Mechanical pressure screw.

Advantage

KUKKO internal extractors can be combined with counter supports and slide hammers.
Almost all components available as replacement parts, time-saving order process thanks to numbering system.

KUKKO quality standards

Quality made in Germany.
Strong design, high performance and long service life.
Application Video by QR Code directly available on the tool.

Series 21-E

Item no.	EAN 4021176	Ball-bearing ISO	Inner diameter of the ball bearing mm	Inner diameter of the ball bearing inch	Operating depth mm	Operating depth inch	Length of the internal extractor mm	Length of the internal extractor inch	Number of segments	Size of internal extractor mm	Size of internal extractor mm	Weight kg
21-0-E	909153	625; 635	4,8 - 6,5	3/16 - 1/4	30	1 3/16	54	2 1/8	2	10	13	0.05
21-00-E	909160	607; 627; 608; 619/8; 628/8; 609; 618/9; 629	6,8 - 9,5	1/4 - 3/8	30	1 3/16	54	2 1/8	2	10	13	0.05
21-01-E	909177	6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300; 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301	9,5 - 12,5	3/8 - 1/2	30	1 3/16	54	2 1/8	2	10	13	0.05
21-1-E	930003	6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301; 6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902	12 - 16	3/16 - 5/8	35	1 3/8	80	3 3/16	3	14	22	0.17
21-2-E	931000	6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902; 6003; 6203; 6303; 6403; 6803; 6903; 16003; 61803; 61903	14 - 19	5/8 - 3/4	40	1 5/8	83	3 1/4	3	14	22	0.175
21-3-E	931109	6004; 6204; 6304; 6404; 6804; 6904; 16004; 61804; 61904	18 - 23	3/4 - 7/8	50	2	90	3 1/2	3	14	22	0.21
21-4-E	909191	6005; 6205; 6305; 6405; 6805; 6905; 16005; 61805; 61905; 6006; 6206; 6306; 6406; 16006; 61806; 61906	24 - 34	7/8 - 1 3/8	58	2 1/4	98	3 7/8	3	17	22	0.25
21-5-E	924071	6007; 6207; 6307; 6407; 16007; 61807; 61907; 6008; 6208; 6308; 6408; 16008; 61808; 61908; 6009; 6209; 6309; 6409; 16009; 61809; 61909	34 - 48	1 3/8 - 1 7/8	65	2 5/8	110	4 3/8	4	19	24	0.215
21-6-E	924088	6010; 6210; 6310; 6410; 16010; 61810; 61910; 6011; 6211; 6311; 6411; 16011; 61811; 61911; 6012; 6212; 6312; 6412; 16012; 61812; 61912	48 - 63	1 7/8 - 2 1/2	80	3 3/16	120	4 3/4	6	24	32	0.71
21-7-E	924095	6013; 6213; 6313; 16013; 61913; 6014; 6214; 6314; 16014; 6015; 6215; 6315; 16015	63 - 78	2 1/2 - 3 1/16	80	3 3/16	120	4 3/4	6	24	32	0.86
