Kukko 46-1-B 2-Arm Universal Abzieher 300 x 300 mm mit schwenkb. Abzughaken und Hydraulikspindel
Product number:
1934556
Manufacturer no.:
46-1-B
EAN:
4021176017018
Weight in kg:
19.22
Product information "Kukko 46-1-B 2-Arm Universal Abzieher 300 x 300 mm mit schwenkb. Abzughaken und Hydraulikspindel"
Kukko 46-1-B 2-jaw puller with long hydraulic spindle and swiveling jaws (incl. Mech. spindle)
For pulling particularly tight bearings, gears, discs, etc.
Description
- Grease hydraulics.
- Swivelling standard puller jaws.
- Two-arm design for space-saving operation.
- 2-jaw and 3-jaw combination cross beam.
- Hydraulic spindle and mechanical pressure screw.
- Milled thread treated with special coating.
- If there is adequate free space around the part to be removed, we recommend using a 3-jaw puller series 47 for optimal distribution of force.
Advantage
- Combi-pullers can be used as a 3-jaw and 2-jaw puller.
- The larger the pulling force, the stronger the puller hook's grip on the workpiece to be removed.
- Spindle head band prevents the wrench from slipping off.
- Almost all components available as replacement parts, time-saving order process thanks to numbering system.
KUKKO quality standards
- Quality made in Germany.
- Strong design, high performance and long service life.
- Safety label to ensure protection of intellectual property.
- A tube of KUKKO special grease included for pressure spindle.
Series 46
| Item no. | EAN 4021176 |
Clamping reach outside mm |
Clamping reach outside inch |
Clamping depth mm |
Clamping depth inch |
Hex drive size mm |
Max. tonne t |
Max. torque Nm |
Weight kg |
| 46-1-B | 017018 | 300 | 11 7/8 | 300 | 11 7/8 | 36 | 15 | 45 | 14.6 |
| 46-2-B | 017278 | 500 | 19 3/4 | 450 | 17 3/4 | 36 | 15 | 45 | 16 |
