Kukko 482-3 2-Arm Puller 150 X 150 Mm Au togrip Type
Product number:
1935127
Manufacturer no.:
482-3
EAN:
4021176479939
Weight in kg:
0.88
Product information "Kukko 482-3 2-Arm Puller 150 X 150 Mm Au togrip Type "
Kukko 482-3 Universal 2-jaw puller with Auto-Snap
For removing bearings, gears, discs, etc. for tight or difficult-to-access spaces.
Description
- Automatic tensioning and centering of the extractor jaws.
- Thanks to the integrated force transmission via the spring mechanism, the clamping force increases in proportion to the pulling force.
- Two-arm design for space-saving operation.
- Optimal adjustment of the spindle to the shaft with 2-sided spindle tip (ball and tip).
- Mechanical pressure screw.
- Milled thread treated with special coating.
Advantage
- The elastic effect and slim design enables parts to be pulled in difficult-to-reach places.
- Almost all components available as replacement parts, time-saving order process thanks to numbering system.
KUKKO quality standards
- Quality made in Germany.
- Strong design, high performance and long service life.
- Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI).
- Safety label to ensure protection of intellectual property.
- A tube of KUKKO special grease included for pressure spindle.
Series 482
| Item no. | EAN 4021176 |
Clamping reach outside mm |
Clamping reach outside inch |
Clamping depth mm |
Clamping depth inch |
Hex drive size mm |
Max. tonne t |
Max. torque Nm |
Weight kg |
| 482-1 | 479779 | 15 - 60 | 5/8 - 2 3/8 | 40 | 1 5/8 | - | 1,5 | - | 0.235 |
| 482-2 | 479854 | 20 - 85 | 3/4 - 3 3/8 | 90 | 4 | - | 1,5 | - | 0.275 |
| 482-3 | 479939 | 150 | 5 7/8 | 150 | 5 7/8 | 10 | 2,5 | 35 | 0.875 |
| 482-4 | 480096 | 200 | 7 7/8 | 200 | 7 7/8 | 13 | 3 | 40 | 1.68 |
| 482-5 | 480171 | 250 | 9 7/8 | 250 | 9 7/8 | 13 | 3 | 40 | 1.92 |
