Kukko 612075 Druckspindel M12X75 Vergütet U. Brüni ert Sw 19

Product information "Kukko 612075 Druckspindel M12X75 Vergütet U. Brüni ert Sw 19 "

Kukko Mechanical pressure spindle


As a replacement part or supplement to your Kukko puller.


Description

  • The pressure spindles are specially coated to ensure particularly good sliding properties in the thread.
  • KUKKO pressure spindles with milled thread have been specifically engineered for use in KUKKO pullers.
  • Optimal adjustment of the spindle to the shaft with 2-sided spindle tip (ball and tip).
  • The mounted, freely-rotating centring point protects the shaft against damage when applying the pulling force.
  • Only complete with KUKKO safety-first label.
  • A tube of KUKKO special grease included for pressure spindle.
  • Quality made in Germany.

Advantage

  • The spindle heads have a band which prevents the wrench from slipping during the removal process.
  • The spindle head and the spindle collar are lasered with the item number.


Series 6

Item no. EAN
4021176
Thread Diameter
of the thread
mm
Length of the spindle
mm
Measuring the thread
mm
Size
mm
Two-sided
stem tip
Mounting diam.
the stem tip
mm
Weight
kg
608080 176241 M 8x1,25 8 80 3,75 - - - 0.045
608130 481086 M 8x1,25 8 130 3,75 - - - 0.06
609087 102493 M 9x1,25 9 87 3,75 - - - 0.055
609105 101403 M9 x 1,25 9 105 3,75 - - - 0.06
610070 362446 M10x1,5 10 75 4,50 13 - - 0.055
610094 122118 M10x1,5 10 94 4,50 - - - 0.115
610110 433726 M10x1,5 10 120 4,50 8 - - 0.065
610120 910005 M10x1,5 10 120 4,50 13 - - 0.12
612080 238468 M 12x1,5 12 85 4,50 13 612140 6,4 0.085
612110 112881 M 12x1,5 12 110 4,50 13 612140 6,4 0.115
612130 077081 M 12x1,5 12 130 4,50 13 612140 6,4 0.115
612150 790201 M 12x1,5 12 150 4,50 13 - - 0.13
612200 056208 M 12x1,75 12 210 5,25 13 612140 6,4 0.22
614135 074271 M 14x1,5 14 135 4,50 17 612140 6,4 0.19
614160 112966 M 14x1,5 14 160 4,50 17 612140 6,4 0.22
614200 838576 M 14x1,5 14 200 4,50 17 612140 6,4 0.26
614250 306709 M 14x1,5 14 250 4,50 17 612140 6,4 0.31
616160 284236 M 16x1,5 16 145 4,50 17 - - 0.265
616202 264351 M16x2,0 16 185 6,00 17 616180 10,4 0.32
616220 420856 M 16x1,5 16 220 4,50 17 616180 10,4 0.36
616270 480829 M 16x2,0 16 270 6,00 17 616180 10,4 0.405
616325 480904 M 16x2,0 16 325 6,00 17 - - 0.5
618068 123771 M 18x1,5 18 58 4,50 19 - - 0.175
618105 073779 M 18x1,5 18 105 4,50 19 616180 10,4 0.25
618175 056215 M 18x1,5 18 175 4,50 19 616180 10,4 0.375
618210 113048 M 18x1,5 18 210 4,50 19 616180 10,4 0.435
620172 817946 M 20x2,5 20 170 7,50 24 620260 12,5 0.59
620230 818028 M 20x2,5 20 230 7,50 24 - - 0.715
620250 818103 M 20x2,5 20 250 7,50 24 - - 0.76
621130 124358 G 1/2" / 14 20,955 130 5,40 22 620260 12,5 0.395
621170 067181 G 1/2" / 14 20,955 170 5,40 22 620260 12,5 0.45
621220 268373 G 1/2" / 14 20,955 220 5,40 22 620260 12,5 0.61
621300 765346 G 1/2" /14 20,955 300 5,40 22 620260 12,5 0.795
621355 236228 G 1/2" / 14 20,955 355 5,40 22 620260 12,5 0.94
623150 018961 G 5/8" / 14 22,911 150 5,40 24 - - 0.54
623170 124501 G 5/8" / 14 22,911 170 5,40 24 620260 12,5 0.61
623230 074684 G 5/8" / 14 22,911 230 5,40 24 620260 12,5 0.76
623260 113123 G 5/8" /14 22,911 260 5,40 24 620260 12,5 0.86
623325 125263 G 5/8" / 14 22,911 325 5,40 24 620260 12,5 1.055
623360 814976 G 5/8" / 14 22,911 360 5,40 24 - - 1.15
623450 832796 G 5/8" / 14 22,911 450 5,40 24 - - 1.43
626300 765360 G 3/4" / 14 26,441 300 5,40 27 620260 12,5 1.32
626400 125423 G 3/4" / 14 26,441 400 5,40 27 620260 12,5 1.66
626500 765377 G 3/4" / 14 26,441 500 5,40 27 620260 12,5 2.085
633400 765384 G 1" / 11 33,249 400 6,90 36 - - 2.71
633500 893452 G 1" / 11 33,249 500 6,90 36 - - 3.43
633600 866388 G 1" / 11 33,249 600 6,90 36 - - 4.05
637350 893469 G 1.1/8 / 11 37,897 350 6,90 36 - - 3.12
637500 895609 G 1.1/8" / 11 37,897 500 6,90 41 - - 4.24
637600 169236 G 1.1/8" / 11 37,897 600 6,90 41 633370 18,9 5.275
638300 059230 W 1.1/2" - 322 - 24 - - 2.68
