Stahlwille 4014 75 Combination spanner
€673.95*
Content:
1 pcs
/ 4
Delivery time 4 working days
Variante
Product number:
1867196
Manufacturer no.:
40147575
EAN:
4018754226481
Weight in kg:
6.5
Product information "Stahlwille 4014 75 Combination spanner "
Stahlwille 4014 75 Combination spanner Spanner size 75 mm L.810mm
Features:
- metric, equal spanner widths
- Mouth position 15°
- Ring with double hexagon
- Ring side offset by 10°
- Chrome alloy steel, chrome-plated
Technical features:
- a1: 26 mm
- a2: 38 mm
- Width mm (b): 153 mm
- d: 110 mm
- DIN: DIN 3113 Form A
- Length mm (L): 810 mm
- Jaw angle: 10 °
- Ring position: 10 °
- Spanner width 1 [mm]: 75 mm
- Spanner width 2 [mm]: 75 mm
- t: 57,5 mm
- Weight: 6500 g
- Weigth kg: 6.5 kg
Stahlwille 4014 75
Stahlwille product no: 40147575
EAN: 4018754226481
| Design/type: | angled, offset, standard length |
|---|---|
| Size: | 75 mm |
| Spanner type: | Combination spanner |
| Unit of measurement: | metric (mm) |
