Stahlwille 721QR/20 QUICK Torque Wrench With Cut-O ut
Product number:
1902616
Manufacturer no.:
50204120
EAN:
4018754268962
Weight (kg):
1.34
Product information "Stahlwille 721QR/20 QUICK Torque Wrench With Cut-O ut"
Stahlwille 721QR/20 QUICK Torque wrench MANOSKOP Model 721QR/20 Quick Measuring r. 40-200N·m Drive 1/2 L. 482mm
Features:
- Click-type
- Flash adjustment with easy-to-operate clamping lever in the handle
- Ratchet with QuickRelease safety lock
- Dual stop signal
- Dual scale N-m/ft-lb
- No need to reset to "0" as measuring element is only loaded during the tightening process
- Further load after release or loads against the direction of operation, e.g. in the case of tight screws, have no effect. The release mechanism is protected from damage by the sturdy tubular steel housing
- Protection of all sensitive parts
- Calibration with the perfectControl calibration device no. 7794 or the calibration unit no. 7706. Readjustment without disassembly if necessary.
- with certificate in accordance with DIN EN ISO 6789-2:2017
- Display deviation ± 4 %
Technical features:
- Scale division N·m: 5 N·m
- Scale division ft·lb: 5 ft·lb
- Measuring range N·m: 40-200 N·m
- Measuring range ft·lb: 30-145 ft·lb
- External square drive (inch): 1/2
- b1: 28 mm
- b2: 41 mm
- DIN: DIN EN ISO 6789-2:2017
- Size: 20
- Height mm (h1): 23 mm
- Height mm (h2): 18 mm
- Length mm (L): 482 mm
- LF: 416,5 mm
- MA N·m: 40 N·m
- Nominal value N·m: 200 N·m
- Weight: 1338 g
- Weigth kg: 1.34 kg
Stahlwille 721QR/20 QUICK
Stahlwille product no: 50204120
EAN: 4018754268962
| Drive: | 1/2" (12.5 mm) |
|---|---|
| Torque Tools: | Mechanical torque wrench |
| Torque range: | 40-200 N·m |
