BGS 8515 Universal Engine Support with 2- and 3-po int Receptacles, 315 kg

€100.95*

Content: 1 pcs

Delivery time 5 working days

Stk

Product number: 1913308

Manufacturer no.: 8515

EAN: 4026947085159

Weight (kg): 12.28

Product information "BGS 8515 Universal Engine Support with 2- and 3-po int Receptacles, 315 kg"

BGS 8515 Universal Engine Support with 2- and 3-point Receptacles, 315 kg

BGS 8515 Universal Engine Support with 2- and 3-point Receptacles, 315 kg
2- and 3-point support on car wing edges and hood latch
support is provided on the fender screw edges and, if necessary, on the radiator support
wide area of application due to adjustable suspension points
incl. 2 pendant ropes
cross beams width: 1000 - 1550 mm
longitudinal beam length: 24-fold adjustable: 90, 120, 150, 180, 210, 240, 270, 300, 330, 360, 390, 420, 450, 480, 510, 540, 570, 600, 630, 660, 690, 720, 750, 780 mm
supporting foot height (longitudinal beam): 100 - 130 - 160 - 185 - 210 - 240 mm
supporting foot height (cross beams): 105 mm
capacity: 315 kg
