Fertan Underbody and Cavity Gun
Features:
Large riser tube for waxes completely made of metal.
With cavity probe 600 mm and 360° nozzle.
Ideal for processing Fertan HT cavity protection wax, UBS 240 underbody protection wax and stone chip protection.
Technical features:
Air consuption: 300 l / min
Pressure: 2 - 8 bar
Inner hose diameter: 10 mm
Power: Min. 350 / 100 l (2,2 - 3 kW)
Air supply connection: 1/4"
Fertan Prewax pre-treatment wax, 500 ml
Pre-treatment wax for car bodies
Perfect for welds and overlaps
Features:
PREWAX is a specially developed pre-treatment wax for auto bodies. It is applied in order to protect metal seams that have previously been treated using FERTAN Rust Converter. PREWAX leaves a fine, extremely stable wax layer that penetrates into crevices. An addtionaly final coat of Underbody Protection Wax UBS 220 should be applied to underbodies, and cavities, sills, etc. should receive a final coating of HT Cavity Protection Wax.
PREWAX's penetrating power insures that even overlapping sheets of metal and compounds are well protected at their welds and seams. The product can also be sprayed on to metal as a final protective coating, leaving behind a very thin but stable film. Residues are easily removed with mineral spirits.
Highly flamable
Irritant
Environment damaging
Usage:
Spray directly onto folds or metal overlaps from a short distance. For cavities, sills, etc. use the included 4 mm applicator probe to spray directly into the cavity, allowing for slow and complete penetration.
Penetration should be clearly visible at welds and overlaps.
Because of the viscosity of the product, some run-off should be expected.
Cover the floor during application and clean off residue as soon as possible with mineral spirits.
Coating gun TBS 222 G2
The perfect solution to the problem of cavity sealing: our powerful gun has been specially developed to distribute the protective agent evenly and effectively in all cavities, even in hard-to-reach areas. So that your vehicle is optimally protected and preserved.
Features:
Thanks to the innovative 360° nozzle, the material is finely distributed and you can be sure that every area is adequately protected. No matter how thick the material is, our gun ensures even distribution without any problems.
For the use of cavity wax, we offer the proven pressure cup method. Our system makes it possible to apply the wax precisely and efficiently, even when using long, thin probes. With our pressure cup method, you get a fine spray mist directly at the nozzle, which ensures optimum sealing.
Our gun is versatile and can also be used for other anti-corrosion products such as Mike Sanders anti-corrosion grease or Fertan preservative wax.
With adjustable flow control, bleed valve and spray air adjustment, our gun offers maximum control and flexibility of application.
Scope of delivery:
Compressed air cup gun with straight nozzle (can therefore also be used without probe)
1 probe set, consisting of hose and 3 nozzles
Hook probe (90° angled) with handle and flat nozzle (can also be used for the "targeted" application of underbody protection) - length with hose approx. 170 cm
360° probe for cavity sealing - length with hose approx. 155 cm
Round jet nozzle - length with hose approx. 155 cm
Technical features:
Net weight: 1061 g
Air connection: Quick-release coupling
Air Nozzle diameter: 1.2 mm
Air consumption: approx. 200-300 L/min
Max. pressure: 8 bar / 116 PSI
Working pressure: 3-4 bar / 43-58 PSI
Filling volume: 1 litre
Gun body: Aluminium
Finger guard on handle
Opening for hanging up
Finish: Powder-coated, black
Valve: Brass/stainless steel
Recommended max. hose length: 10 m
Min. internal hose cross-section: 6 mm
EAN: 4260208060961
Fertan Underbody protection wax, 1 Liter
Features:
Fertan UBS 240 is an underbody protection wax for long-term protection
PVC-compatible, in a transparent to slightly amber color.
The "amber effect" is reinforced, the more of the product is being applied.
Fertan UBS 240 is an ideal protective wax-based product, especially for underbodies of motor vehicles
Can be used even in extreme conditions to protect over long term.
Fertan can also be applied to lacquered underbodies.
Highly flammable
Irritant
Environmental damaging
FLUID FILM AS-R 400 ml Spray can
FLUID FILM AS-R as 400 ml spray can is a universal product for maintenance, preservation, rust dissolving and as a lubricant.
400 ml spray can
Viscosity: low (eg. like sirup)
Creep ability: + + + +
Protection: ca. 4 years (in closed cavities)
Processing: Spray can with additional fine applicator
General usage:
FLUID FILM AS-R is a physiologically harmless, solvent-free and thixotropic one-layer corrosion protection coating with slip and rust dissolving effect based on lanolin and forms a clear and glossy protective film.
The 400 ml spray can contains FLUID FILM NAS with propane-butane as propellant.
400 ml spray can as a universal product for commercial and private use for maintenance, preservation, rust dissolving and as a lubricant.
FLUID FILM AS-R is very suitable for factories, workshops, garages and the do-it-yourselfer for use as a preservative, maintenance product, rust remover and lubricant.
On the car it provides protection for folds, door edges, cavities, engine compartment as well as for all other parts at risk of corrosion. Especially when shut down in winter, even a thin film of FLUID FILM AS-R protects even motorcycles, bicycles or boat parts from rust, also on chains, joints and metal surfaces, such as machines and tools, corrosion is stopped immediately or does not occur at all.
By combining it as a corrosion inhibitor and lubricant, moving parts such as idler pulleys, chain transmissions or joints can be protected.
FLUID FILM AS-R can be used very effectively for the maintenance of sports, leisure and household equipment or in the restoration sector, where special attention is paid to the original patina.
Unlike conventional products, FLUID FILM AS-R is more environmentally friendly and economical to use due to its solvent-free composition.
The basic substance lanolin is not volatile like oil or kerosene and does not resinify.
In contrast, the effect of solvents usually wears off after 12-15 seconds, and that of oil or kerosene ends after a few days, at which point these conventional agents completely lose their protective effect.
The insert from the 400 ml spray can allows an even application on large surfaces with the normal spray attachment.
For pinpoint use even in difficult-to-reach places, there is a 15 cm long spray tube on the can. For use in longer cavities, an approx. 60 cm long spray head extension with a 3-jet all-round nozzle can be supplied.
Application:
Untergrundvorbereitung:
Surface may be dry or wet, loose dirt and rust to be removed.
Surfaces may still be wet but without surface water.
Application:
Spray FLUID FILM evenly on cleaned, dry or wet
surfaces. If needed, repeat application.
Hard-to-reach areas to be coated by means of
the sprayhead with spraytube.
Coating can be removed easily with fuel and
other degreasing agents.
Storage:
To be stored in a cool and dry place.
Recommended storage temperature: 15-35°C
Pressurized gas packaging can be stored for 2 years.
Principal characteristics:
Behaves extremely resistant to all weather conditions, including snow and slush and the solvent salts used in winter service.
Extremely effective and reliable at the same time as a rust remover and water-displacing corrosion inhibitor.
Excellent salt water resistance.
As corrosion protection of steel parts and other metal parts during transport and processing in the manufacturing plant.
Fast creeping, yet well adhering, temperature stable, will not be washed off or altered by rain and sea water, nor will it evaporate and gum up, as is the case with most penetrating oils.
Bitumen protection layers already on the car chassis floors are plasticized by FLUID FILM and thus activated.
Fertan Rust Converter, 1 Liter
The FERTAN rust converter is the perfect rust converter. With the FERTAN rust converter you can easily remove strong rust. For optimal rust removal.
Features:
1 litre standard dose
for the removal of rust and corrosion of carbon steel
for vehicles, vehicle parts and fuel tanks, car body cavities
for metal constructions, ships, ship parts, port facilities
for steel halls, conservatories and other carbon steel components
Proven for decades in restoration
the surface to be treated must be free of dirt, oil, grease and silicone, i. e. metallically clean, but not rust-free
Fertan Rust converter advantages:
As a rust converter, FERTAN dissolves the existing rust layer (Fe3) and decomposes it into a non-reactive powder.
The non-corrosive Fe2 layer underneath is protected with the new metal bond and the previously corroded metal can be provided with the required final protection within 6 months.
This can be used in paint, varnish, wax, tar, zinc, epoxy resin, etc. e. be. FERTAN rust converter can be used successfully on slightly rusted, strong rust and also on bare metal.
The protective effect is achieved in principle.
The product is also water-based for environmental reasons. For this reason, the surface to be treated must be free of dirt, oil, grease and silicone, i. e. metallic clean, but not rust-free.
Only with extremely strong rust layers, over 5 mm, a second treatment may be necessary.
However, use FERTAN only at temperatures above 5°C and leave on for about 24 – 48 hours.
Always clean the surface with water before the final treatment.
The FERTAN rust converter can be used even on damp surfaces and is free of pollutants.
Application:
FERTAN Rust converter Application: (Shake before use)
Remove loose rust and prepare a smooth lacquerable surface for the surface to be painted later. (e. g. by grinding)
Before applying FERTAN, it is important to clean surfaces of oil, grease, silicone and dirt.
Apply FERTAN using a clean brush, roller or spray gun.
Temperature information:
Allow FERTAN to act at temperatures above 20°C for 24 hours.
In dry environment or direct sunlight, moisten slightly after 1-2 hours (fog moisture).
At temperatures of 5 – 19° C, extend the reaction time to approx. 48 hours, or longer.
Do not use in frost and temperatures below 5° C!
Surface turns black – blue violet
Ideal for post-treatment after 6 months at the latest: Filler, primer (FERPOX, MM30), colour, cavity protection wash and underbody protection waxes (UBS 240), EP resins etc.
Only rinse the surface with water before further treatment (the surface should not be damaged mechanically, otherwise the protective layer will be destroyed – no grinding, etc. )
This black, blue-violet surface can be overpainted with all conventional primers and varnishes, 1 litre of FERTAN is sufficient for approx. 12 – 15m2 surface when applied with a brush.
FERTAN may cause stains on bright surfaces and absorbent surfaces, so cover them and wash splashes immediately with water, avoiding any open-pored material (e. g. wood, concrete, etc. ) that should not be processed. Clean tools after use with clear water.
Wear protective clothing and follow safety instructions.
Fertan HT Cavity Protection Wax, 1 Litre
FERTAN cavity protection wax was developed for the preservation of car cavities based on wax.
Features:
1 litre normdose
for the end protection of cavities, e. g. in car bodies
The composition of the product allows easy processing without the product flowing out of the cavities.
Due to the presence of resins, an optimal adhesion is achieved, even on vertical surfaces, etc.
HT wax remains very soft and thus obtains the property of automatically closing small cracks in the coating even after years.
for many years successful:
in the restoration of vintage cars
in the restoration of new motor vehicles
Coating of industrial structures
Processing:
Shake well before use.
FERTAN cavity protection Insert wax into the cavities by means of a cavity gun with 360° nozzle. Use the boreholes installed by the vehicle manufacturer or, if necessary, install new boreholes. Apply wax to the edges of the holes.
FERTAN cavity protection Wax does not drip. Remove any splashes with test petrol.
Processing temperature:
The optimum processing temperature and the temperature of the body should be min. 20°C.
For restorations and post-treatment:
Apply wax 24 hours after rust removal by FERTAN rust converters.
Please note the processing instructions for the rust converter.
After rust removal and before application of cavity protective wax, pre-treat the welds and sheet metal overlaps with a layer of PREWAX pre-treatment wax, a seam-penetrating protective wax with extreme creepability.
Then apply cavity protection wax in several thin layers, staggered by 12-48 hours to compensate for shrinkage cracks.
Dry season:
At + 20° C: approx. 5 hours
Consumption:
approx. 5 litres canister for a medium class passenger car
Processing pressure:
cavity suction cup gun with 360° nozzle approx. 6 – 9 bar
cavity pressure cup gun with 360° nozzle approx. 3 – 4. 5 bar
